|1||Cut Pipe Length||Maximum length of raw material 9000, cutting workpiece 0~9000|| |
|2||Cutting pipe diameter||15~350 (external circle of workpiece)|| |
|4||Automatic feeding range||Length||4000~9000|| |
|5||Pipe diameter||20~200|| |
|7||Max. load capacity of a single tube||200||Kg|
|8||Pipe precision requirement||Full-length straightness ≤0.1×diameter, and not more than 10mm||mm|
|9||Minimum tail material||≥0（Related to the length of the workpiece and the actual cutting process||mm|
|10||X、Y axis positioning accuracy||±0.05/1000mm||mm|
|11||X、Y axis repeat positioning accuracy||±0.03/1000mm||mm|
|13||Maximum running speed||60||m/min|
|14||Chuck load weight||400||Kg|
|15||Number of chuck revolutions||80||rpm|
|16||Loading weight||Approx. 24000||Kg|
|17||Dimension (length, width and height)||Approx. 22,360×5412×2650||mm|
|20||Power of the whole machine||Approx. 60||Kw|
|21||Power supply requirements||380v/50Hz|
when the temperature is too low, the cutting effect is mainly manifested in the slow cutting speed, the occurrence of cutting interruption, tempering and increasing resistance after cutting.
The use of laser cutting equipment can improve the blanking efficiency of all single sheet metal, reduce the number of scribes and sheet metal blanking workers, and eliminate the pressure of rising labor costs.
Laser cutting machine adopts non-contact processing. In this processing mode with small heat affected area, the far-reaching significance of laser cutting machine in kitchen utensils processing industry is further reflected.
