|1||Maximum cut pipe length||0~6400 (more than 3 meters need to extend the front joint material)|| |
|2||Cut pipe diameter||16~220 (external circle of workpiece)|| |
|3||Minimum tailstock||90|| |
|4||Feeding range||Suitable for pipe specifications: round pipe, square pipe, rectangular pipe, etc.; loading size: 30mm ≤ external circle diameter ≤ 150mm; 5700mm ≤ L ≤ 6200mm; single pipe weight ≤ 100kg; magazine load range: ≤ 2000KG.|| |
|5||X、Y-axis positioning accuracy||±0.05/1000mm|| |
|6||X、Y-axis repeat positioning accuracy||±0.03/1000mm|| |
|7||Acceleration speed||1.5G|| |
|8||Max. running speed||100|| |
|9||Max. speed of chuck||150|| |
|10||Chuck load weight||Front and rear chucks 120Kg each|| |
|11||Weight of loading machine||8000|| |
|12||Main machine shape (length, width and height)||Approx. 10700×3700×2410|| |
|13||Laser power||1|| |
|14||Control system||cypcut 5000B|| |
|15||Power of the whole machine||34|| |
|16||Power supply requirements||380v/50Hz|| |
when the temperature is too low, the cutting effect is mainly manifested in the slow cutting speed, the occurrence of cutting interruption, tempering and increasing resistance after cutting.
The use of laser cutting equipment can improve the blanking efficiency of all single sheet metal, reduce the number of scribes and sheet metal blanking workers, and eliminate the pressure of rising labor costs.
Laser cutting machine adopts non-contact processing. In this processing mode with small heat affected area, the far-reaching significance of laser cutting machine in kitchen utensils processing industry is further reflected.
If you are interested or have any questions, please call : 18560186916
