|1||Maximum cut pipe length||6500|| |
|2||Cut pipe diameter||10~230 (external circle of workpiece)|| |
|3||Minimum tailstock||≥0 (related to workpiece length and actual cutting)|| |
|5||Pipe diameter D||Round tube 40~230, 50mm ≤ square or rectangular tube external circle wide side ≤ 200mm; tube full length straightness ≤ 0.1D, and the maximum can not exceed 10mm. when the tube diameter or rectangular tube external circle > 150mm, or but to the weight is greater than 150KG, only one tube can be placed at a time.|| |
|6||Load-bearing capacity||≤2000|| |
|7||Maximum load capacity of a single tube||240|| |
|8||X, Y, Z axis positioning accuracy||±0.05/1000mm|| |
|9||X, Y, Z axis repeatability||±0.03/1000mm|| |
|10||Acceleration speed||1.0g|| |
|11||Max. running speed||75|| |
|12||Max. speed of chuck||100|| |
|13||Maximum load weight||240|| |
|14||Weight of loading machine||6500|| |
|15||Main machine shape (length, width and height)||Approx. 13000×4000×2500|| |
|16||Laser power||***|| |
|17||Control system||Pachu 5000A|| |
|18||Power of the whole machine||***|| |
|19||Power supply requirements||380v/50Hz±10%|| |
when the temperature is too low, the cutting effect is mainly manifested in the slow cutting speed, the occurrence of cutting interruption, tempering and increasing resistance after cutting.
The use of laser cutting equipment can improve the blanking efficiency of all single sheet metal, reduce the number of scribes and sheet metal blanking workers, and eliminate the pressure of rising labor costs.
Laser cutting machine adopts non-contact processing. In this processing mode with small heat affected area, the far-reaching significance of laser cutting machine in kitchen utensils processing industry is further reflected.
If you are interested or have any questions, please call : 18560186916
