|1||Maximum cut pipe length||0~2800|| |
|2||Cut pipe diameter||15~230 (external circle of workpiece)|| |
|3||Minimum tailstock||≥0 (related to workpiece length and actual cutting)|| |
|5||Pipe diameter D||Round tube diameter 20~150, square tube 20×20~150×150, straightness of the whole length of the tube ≤0.1D, and the maximum can not exceed 10mm|| |
|6||Load-bearing capacity||≤2000|| |
|7||Maximum load capacity of a single tube||100Kg (Long-term continuous work requires a single tube weight ≤ 70kg)|| |
|8||X, Y, Z axis positioning accuracy||±0.05/1000mm|| |
|9||X, Y, Z axis repeatability||±0.03/1000mm|| |
|10||Acceleration speed||1g|| |
|11||Maximum running speed||75|| |
|12||Chuck speed||100|| |
|13||Max. load weight||240|| |
|14||Weight of loading machine||9000|| |
|15||Main machine shape (length, width and height)||Approx. 12435×4500×2400|| |
|16||Laser power||***|| |
|17||Control system||Bertru 5000A|| |
|18||Power of the whole machine||***|| |
|19||Power supply requirements||380v/50Hz±10%|| |
when the temperature is too low, the cutting effect is mainly manifested in the slow cutting speed, the occurrence of cutting interruption, tempering and increasing resistance after cutting.
The use of laser cutting equipment can improve the blanking efficiency of all single sheet metal, reduce the number of scribes and sheet metal blanking workers, and eliminate the pressure of rising labor costs.
Laser cutting machine adopts non-contact processing. In this processing mode with small heat affected area, the far-reaching significance of laser cutting machine in kitchen utensils processing industry is further reflected.
If you are interested or have any questions, please call : 18560186916
