Product Advantage:
1、Three cards shift each other for fine cutting. Independent research and development of full-stroke chuck, to achieve any length of pipe cutting under the material, as much as possible the use of the whole pipe, to achieve "0 tail material" cutting.
2、Meet the requirements of long workpiece cutting. Compared with the traditional 6 meters pipe cutting, this machine can process a wider range.
3、The bed is welded as a whole, compared with the traditional bed design is more scientific and humanized. The bed performance is more stable and durable.
Product Advantage:
1、Three cards shift each other for fine cutting. Independent research and development of full-stroke chuck, to achieve any length of pipe cutting under the material, as much as possible the use of the whole pipe, to achieve "0 tail material" cutting.
2、Meet the requirements of long workpiece cutting. Compared with the traditional 6 meters pipe cutting, this machine can process a wider range.
3、The bed is welded as a whole, compared with the traditional bed design is more scientific and humanized. The bed performance is more stable and durable.
Project name | Parameter | Unit |
Raw material length | 4000~9000 | mm |
Maximum cut pipe length (cutting length) | 0~9000 | mm |
Cut pipe diameter | 16~350 | mm |
Minimum tailings | ≥0 | mm |
X, Y axis positioning accuracy | ±0.05/1000mm | mm |
X, Y axis repeated positioning accuracy | ±0.03/1000mm | mm |
Working acceleration | 0.8G | m/s² |
maximum operating speed | 60 | m/min |
chuck weight | 400 | Kg |
Chuck rated speed | 80 | rpm |
Installed weight | about 24000 | Kg |
Mainframe shape (length, width and height) | About 23000×5500×2600 | mm |
Power Requirements | 380v/50Hz | V/Hz |
Project name | Parameter | Unit |
Raw material length | 4000~9000 | mm |
Maximum cut pipe length (cutting length) | 0~9000 | mm |
Cut pipe diameter | 16~350 | mm |
Minimum tailings | ≥0 | mm |
X, Y axis positioning accuracy | ±0.05/1000mm | mm |
X, Y axis repeated positioning accuracy | ±0.03/1000mm | mm |
Working acceleration | 0.8G | m/s² |
maximum operating speed | 60 | m/min |
chuck weight | 400 | Kg |
Chuck rated speed | 80 | rpm |
Installed weight | about 24000 | Kg |
Mainframe shape (length, width and height) | About 23000×5500×2600 | mm |
Power Requirements | 380v/50Hz | V/Hz |
*15 years of factory production experience
* 24h after-sales quick solution
* 30,000+ cumulative customers nationwide
24H Online Service
Extensive coverage of 30+ domestic offices and institutions to create a 2-hour service arrival.
Combination of online cloud classroom and offline door-to-door service to meet customer needs in multiple irections and at multiple levels.
Multi-batch customer return visits, timely discovery of problems to solve and improve.
*15 years of factory production experience
* 24h after-sales quick solution
* 30,000+ cumulative customers nationwide
24H Online Service
Extensive coverage of 30+ domestic offices and institutions to create a 2-hour service arrival.
Combination of online cloud classroom and offline door-to-door service to meet customer needs in multiple irections and at multiple levels.
Multi-batch customer return visits, timely discovery of problems to solve and improve.
Q: Do you have CE document and other documents for customs clearance?
A: Yes, we have CE, Provide you with a one-stop service.At first we will show you and and after shipment we will give you CE/Packing list/Commercial Invoice/ Sales contract for customs clearance.
Q: Why the machine price not include fiber source?
Different customers, different requirements, and many different laser power can be optional, that's why we list the price not include fiber source parts.
Q: If we are interested in your machine, how to choose proper power?
Please tell us the following answer, our professional seller will recommend you proper power.
1. What material you want to cut,stainless steel,carbon steel or other?
2. What thickness do you want to cut?
Q:How can I do if the laser cutting machine goes wrong?
A: If confronted with such problems, please contact us asap and do not try
fix the machine by yourself or someone else. We will response within 24 hours as quick as we can to solve it for you.
Q: How about warranty?
A: 3 years quality guaranty, the machine with main parts(excluding the consumables) shall be changed free of charge(some parts
will be maintained) when if any problem during the warranty period.
Q: Do you have after sales support?
A: Yes, we are happy to give advice and we also have skilled technicians available across the
world, We need your machines running in order to keep your business running
Q: Do you have CE document and other documents for customs clearance?
A: Yes, we have CE, Provide you with a one-stop service.At first we will show you and and after shipment we will give you CE/Packing list/Commercial Invoice/ Sales contract for customs clearance.
Q: Why the machine price not include fiber source?
Different customers, different requirements, and many different laser power can be optional, that's why we list the price not include fiber source parts.
Q: If we are interested in your machine, how to choose proper power?
Please tell us the following answer, our professional seller will recommend you proper power.
1. What material you want to cut,stainless steel,carbon steel or other?
2. What thickness do you want to cut?
Q:How can I do if the laser cutting machine goes wrong?
A: If confronted with such problems, please contact us asap and do not try
fix the machine by yourself or someone else. We will response within 24 hours as quick as we can to solve it for you.
Q: How about warranty?
A: 3 years quality guaranty, the machine with main parts(excluding the consumables) shall be changed free of charge(some parts
will be maintained) when if any problem during the warranty period.
Q: Do you have after sales support?
A: Yes, we are happy to give advice and we also have skilled technicians available across the
world, We need your machines running in order to keep your business running
